CP-UNR-208F2-I2
CP-UNR-4K5644-FI
Overview
The CP-UNR-4K5644-FI is a CP-UNR-4K5644-FI from CP Plus, designed for professional IP surveillance in residential, commercial, and industrial environments. Built around a high-sensitivity CMOS sensor, it captures 32 MP, 24 MP, 16 MP, 12 MP, 8 MP, 6 MP, 5 MP, 4 MP, 3 MP, 1080p, 720p, 960p, D1, CIF, QCIF video at up to 30fps with H.265, H.264, MJPEG encoding for bandwidth-efficient storage and streaming. The camera combines reliable performance with easy integration into CP Plus NVR systems and third-party ONVIF-compatible platforms.
Key Features
The CP-UNR-4K5644-FI offers key features capabilities including: Network Camera Sub Categories 2 MP 4 MP 6 MP 8 MP Project Models Project Models Network Video Recorder (NVR) Sub Categories 4 Ch. 8 Ch. 16 Ch. 32 Ch. 64 Ch. 128 Ch. Analog HD Camera Sub Categories 2.4 MP 5 MP.
Technical Capabilities
The CP-UNR-4K5644-FI offers technical capabilities capabilities including: Network Camera Sub Categories 2 MP 4 MP 6 MP 8 MP Project Models Project Models Network Video Recorder (NVR) Sub Categories 4 Ch. 8 Ch. 16 Ch. 32 Ch. 64 Ch. 128 Ch. Analog HD Camera Sub Categories 2.4 MP 5 MP.
Connectivity And Integration
The CP-UNR-4K5644-FI connects via ≤ 13 W (without HDD) over a standard RJ-45 interface, supporting HTTP, HTTPS, TCP/IP, IPv4, UDP, NTP, DHCP, DNS, SMTP, UPnP, DDNS, Alarm Server, Multicast, P2P, Auto Registration, iSCSI, ONVIF 23.12(Profile T/ Profile S/ Profile G), CGI, SDK for broad compatibility with NVR, VMS, and cloud platforms. ONVIF Profile S, G, and T compliance ensures interoperability with third-party recording and management systems without proprietary lock-in. Secure HTTPS and TLS-encrypted RTSP streams protect video data in transit across shared network infrastructure.
Security
The CP-UNR-4K5644-FI implements AES 256-bit encryption along with HTTPS, IP/MAC address filtering, account lockout policies, and syslog support for audit trails. Trusted boot and firmware integrity checks prevent unauthorised firmware from running on the device. The camera is certified to CE, FCC, RoHS, BIS, confirming compliance with international safety and electromagnetic compatibility standards.
Use Cases
The CP-UNR-4K5644-FI is suited for a wide range of security and surveillance applications in commercial, residential, and industrial environments requiring reliable, high-quality video monitoring.
Technical Specifications
| Resolution | 32 MP, 24 MP, 16 MP, 12 MP, 8 MP, 6 MP, 5 MP, 4 MP, 3 MP, 1080p, 720p, 960p, D1, CIF, QCIF |
| Video Compression | H.265, H.264, MJPEG |
| Audio Input | 1 Channel RCA |
| Audio Output | 2 Channel RCA |
| Audio Compression | G.711a, G.711u, PCM, G726, AAC |
| Ethernet | 2 (10/100/1000 Mbps Ethernet port, RJ-45) |
| Protocols | HTTP, HTTPS, TCP/IP, IPv4, UDP, NTP, DHCP, DNS, SMTP, UPnP, DDNS, Alarm Server, Multicast, P2P, Auto Registration, iSCSI, ONVIF 23.12(Profile T/ Profile S/ Profile G), CGI, SDK |
| Storage Temperature | -20 °C to +60 °C (–4 °F to +140 °F) |
| Power Consumption | ≤ 13 W (without HDD) |
| Operating Temperature | –10 °C to +55 °C (14 °F to +131 °F) |
| Dimensions | 440.0 mm × 415.1 mm x 70.0 mm |
| Weight | 4.74 kg (without HDD) |
| Processor | Industrial-grade processor |
| IP Camera Input | 64 Channel |
| Operating System | Embedded LINUX |
| User Interface | Web, Local GUI |
| AI by Camera | Face detection, Face recognition, Video metadata (human, motor vehicles, and non-motor vehicles), Perimeter protection, SMD Plus, Stereo analysis, Crowd distribution, People counting, ANPR, Vehicle density, Heat map |
| AI by NVR | Face detection, Face recognition, Perimeter protection, SMD Plus |
| Perimeter Performance AI by NVR | 4 Channels, 10 IVS rules for each channel |
| Perimeter Performance of AI by Camera | All Channels (16 targets/s) |
| Video Output | VGA:1920 × 1080, 1280 × 1024, 1280 × 720; HDMI:3840 × 2160, 1920 × 1080, 1280 × 1024, 1280 × 720 |
| Face Detection AI by NVR | 2 channels (up to 12 face images/s each channel) |
| Face Detection By Camera | 16 channels |
| Abnormality Alarm | Camera offline, Storage error, Disk full, IP conflict, MAC conflict, Login lock, Abnormal behaviour of fan, Cyber security exception |
| Face Attributes | Gender, Age group, Glasses, Expressions, Face mask, Beard |
| Face Database Capacity | Up to 20 face databases with 20,000 images, with a total capacity of 2.5 G. Name, Gender, Birthday, Address, Credential type, Credential No., Countries & Regions and state can be added to each face image |
| SMD Plus by NVR | 8 channels: Secondary filtering for human and motor vehicle, Reducing false alarms caused by leaves, Rain and lighting condition change |
| Face Recognition AI by NVR | 1. 16-channel FD (by camera) + FR (by recorder), image stream: 16 face images/s 2. 2-channe FD (by recorder) + FR (by recorder), video stream: 12 face images/s |
| Face Recognition AI by Camera | 16 Channels |
| SMD By Camera | All Channels (32 targets/s) |
| Network Bandwidth | AI disabled: 384 Mbps incoming, 384 Mbps recording and 384 Mbps outgoing AI enabled: 200 Mbps incoming, 200 Mbps recording and 200 Mbps outgoing |
| Network Mode | Multi-address mode, load balance, fault tolerance and other network port binding modes |
| IntelliCheck AI by Camera + Recorder | Max. 32 Channel, 1 Combined event per Channel/s |
| Multi-channel | Up to 16 channels |
| Video Metadata By Camera | 8 Channels |
| ANPR by Camera (Number of Channels) | All Channels (8 targets/s) |
| Encode Strategy | Instastream, H.264+ |
| Video Display Split | Main screen: 1/4/8/9/16/25/36/64 Sub screen: 1/4/8/9/16 |
| Decoding Capability | AI disabled: 2 Channel 32 MP@25 fps, 2 Channel 24 MP@25 fps, 4 Channel 16 MP@30 fps, 5 Channel 12 MP@30 fps, 8 Channel 8 MP@30 fps, 10 Channel 6 MP@30 fps, 12 Channel 5 MP@30 fps, 16 Channel 4 MP@30 fps, 32 Channel 1080p@30 fps AI enabled: 1 Channel 32 MP@25 fps, 1 Channel 24 MP@25 fps, 2 Channel 16 MP@30 fps, 4 Channel 12 MP@30 fps, 6 Channel 8 MP@30 fps, 8 Channel 6 MP@30 fps, 8 Channel 5 MP@30 fps, 12 Channel 4 MP@30 fps, 24 Channel 1080p@30 fps |
| Non-motor Vehicle | Vehicle model, Vehicle color, Number of persons, Helmet. |
| License Plate Database Capacity | 1. Create up to 20,000 plate numbers. 2. Blocklist and allow list |
| Motor Vehicle Attributes | License plate, Plate color, Vehicle body, Vehicle model, Vehicle logo, Calling, Seatbelt, Vehicle interior, Vehicle registration location |
| Human Attributes | Top color, Top type, Bottom color, Bottom type, Hat, Bag, Age, Gender and Umbrella |
| Alarm Input | 16 Channels |
| Alarm Output | 6 Channels (1 Channel 12 V 1 A output) |
| Disk Group | Support |
| Disk Interface | 4 SATA ports, each disk can contain up to 20 TB. This limit varies depending on the environment temperature |
| General Alarm | Motion detection, Local alarm, Alarm box, Camera external alarm, Network alarm, Scene changing, PIR alarm, Thermal alarm |
| Intelligent Alarm | Face detection, Perimeter protection, Face recognition, Video metadata (Human, Motor vehicles, and non-motor vehicles), SMD Plus, Stereo analysis, Crowd distribution, People counting, ANPR, Vehicle density, Heat map |
| Recording Mode | General, Motion detection, Intelligent, Alarm, POS |
| Playback | instant playback, General playback, Event playback, Tag playback, Smart playback (face and motion detection) |
| Backup Mode | USB device and network |
| Alarm Linkage | Record, Snapshot, Local alarm output, IPC external alarm output, Access controller, Audio, Buzzer, Log, Preset, Email |
| Interface Ports | 3 (1 front USB 2.0 port, 2 rear USB 3.0 ports), 2 HDMI, 2 VGA, 1 RS232, 1 eSATA Port, 1 RS485 |
| Smart Phone | iPhone, iPad, Android Phone |
| Power Supply | 100–240 VAC, 50-60 Hz |
| Operating Humidity | 10%–93% (RH), non-condensing |
