CP Plus
CP Plus
CP-UNR-108F1
CP-UNR-4K5322-FI
Overview
The CP-UNR-4K5322-FI is a CP-UNR-4K5322-FI from CP Plus, designed for professional IP surveillance in residential, commercial, and industrial environments. Built around a high-sensitivity CMOS sensor, it captures 32MP, 24MP, 16MP, 12MP, 8MP, 5MP, 4MP, 1080p, 720p, D1, CIF, QCIF video at up to 30fps with H.265, Smart H.264+, H.264, MJPEG encoding for bandwidth-efficient storage and streaming. The camera combines reliable performance with easy integration into CP Plus NVR systems and third-party ONVIF-compatible platforms.
Key Features
The CP-UNR-4K5322-FI offers key features capabilities including: Network Camera Sub Categories 2 MP 4 MP 6 MP 8 MP Project Models Project Models Network Video Recorder (NVR) Sub Categories 4 Ch. 8 Ch. 16 Ch. 32 Ch. 64 Ch. 128 Ch. Analog HD Camera Sub Categories 2.4 MP 5 MP.
Technical Capabilities
The CP-UNR-4K5322-FI offers technical capabilities capabilities including: Network Camera Sub Categories 2 MP 4 MP 6 MP 8 MP Project Models Project Models Network Video Recorder (NVR) Sub Categories 4 Ch. 8 Ch. 16 Ch. 32 Ch. 64 Ch. 128 Ch. Analog HD Camera Sub Categories 2.4 MP 5 MP.
Connectivity And Integration
The CP-UNR-4K5322-FI connects via ≤ 10 W (without HDD) over a standard RJ-45 interface, supporting HTTP, HTTPS, TCP/IP, IPv4/IPv6, RTSP, UDP, SNMP, NTP, DHCP, DNS, SMTP, UPnP, IP Filter, PPPoE, FTP, DDNS, Alarm Server, IP Search, Multicast, InstaOn, Auto Connect, ONVIF (Profile T, Profile S, Profile G), CGI, SDK for broad compatibility with NVR, VMS, and cloud platforms. ONVIF Profile S, G, and T compliance ensures interoperability with third-party recording and management systems without proprietary lock-in. Secure HTTPS and TLS-encrypted RTSP streams protect video data in transit across shared network infrastructure.
Security
The CP-UNR-4K5322-FI implements AES 256-bit encryption along with HTTPS, IP/MAC address filtering, account lockout policies, and syslog support for audit trails. Trusted boot and firmware integrity checks prevent unauthorised firmware from running on the device. The camera is certified to CE, FCC, RoHS, BIS, confirming compliance with international safety and electromagnetic compatibility standards.
Use Cases
The CP-UNR-4K5322-FI is suited for a wide range of security and surveillance applications in commercial, residential, and industrial environments requiring reliable, high-quality video monitoring.
Technical Specifications
| Resolution | 32MP, 24MP, 16MP, 12MP, 8MP, 5MP, 4MP, 1080p, 720p, D1, CIF, QCIF |
| Video Compression | H.265, Smart H.264+, H.264, MJPEG |
| Audio Input | 1-channel RCA |
| Audio Output | 1-channel RCA |
| Audio Compression | G.711a, G.711u, PCM, G726, AAC |
| Ethernet | 1 x (10/100/1000 Mbps Ethernet port, RJ-45) |
| Protocols | HTTP, HTTPS, TCP/IP, IPv4/IPv6, RTSP, UDP, SNMP, NTP, DHCP, DNS, SMTP, UPnP, IP Filter, PPPoE, FTP, DDNS, Alarm Server, IP Search, Multicast, InstaOn, Auto Connect, ONVIF (Profile T, Profile S, Profile G), CGI, SDK |
| Storage Temperature | -20 °C to +60 °C (–4 °F to +140 °F) |
| Power Consumption | ≤ 10 W (without HDD) |
| Operating Temperature | -10 °C to +55 °C (14 °F to +131 °F) |
| Dimensions | 375.0 mm × 284.4 mm x 56.0mm |
| Weight | 1570g (without HDD) |
| Processor | Industrial-grade processor |
| IP Camera Input | 32 channel |
| Operating System | Embedded LINUX |
| User Interface | Web, Local GUI |
| Video Output | 1 Channel VGA, 1 Channel HDMI video output. Heterogeneous video source output for HDMI and VGA Supports 4K display |
| Encode Strategy | Instastream |
| Decoding Capability | AI disabled: 2 Channel 32MP@20 fps, 2 Channel 24MP@20 fps, 4 Channel 16MP@30 fps, 5 Channel 12MP@30fps, 8 Channel 8MP@30 fps, 12 Channel 5MP@30fps, 16 Channel 4MP@30 fps, 32 Channel 1080p@30fps AI enabled: 1 Channel 32MP@20 fps, 1 Channel 24MP@20 fps, 2 Channel 16MP@30 fps, 4 Channel 12MP@30 fps, 4 Channel 8MP@30 fps, 8 Channel 5MP@30 fps, 12 Channel 4MP@30 fps, 24 Channel 1080p@30fps |
| AI by NVR | Face detection, Face recognition, Perimeter protection, IMD+ |
| AI by Camera | Face detection, Face recognition, Video metadata (Human, Motor vehicles, and non-motor vehicles), Perimeter protection, IMD+, Stereo analysis, Crowd distribution, People counting, ANPR, Vehicle density, Heat map |
| Network Bandwidth | AI disabled: 384 Mbps Incoming, 384 Mbps Recording and 384 Mbps Outgoing AI enabled: 200 Mbps Incoming, 200 Mbps Recording and 200 Mbps Outgoing |
| Video Display Split | Main screen: 1/4/8/9/16/25/36 Sub screen: 1/4/8/9/16 |
| Perimeter Performance AI by NVR (Number of Channels) | 4 Channels, 10 IVS rules for each channel |
| Perimeter Performance of AI by Camera (Number of Channels) | Human and vehicle detection on all channels, supporting up to 16 targets per second |
| Face Attributes | Gender, Age group, Glasses, Expressions, Face mask, Beard |
| Face Detection Performance of AI by NVR (Number of Channels) | 2 Channels (up to 12 face images/s each channel) |
| Face Detection Performance of AI by Camera (Number of Channels) | 16 Channels |
| Face Database Capacity | Up to 20 face databases with 20,000 images, with a total capacity of 2.5 G. Name, Gender, Birthday, Address, Credential type, Credential No., Countries & Regions and state can be added to each face image |
| Face Recognition Performance of AI by NVR (Number of Channels) | 1.16 Channel FD (by camera) + FR (by recorder), image stream: 16 face images/s 2.2 Channel FD (by recorder) + FR (by recorder), video stream: 12 face images/s |
| Face Recognition Performance of AI by Camera | 16 channels |
| IMD+ by NVR | 8 Channels: Secondary filtering for human and motor vehicle, reducing false alarms caused by leaves, rain and lighting condition change |
| IMD By Camera | Human and vehicle detection on all channels, supporting up to 32 targets per second |
| Metadata Performance of AI by Camera (Number of Channels) | 8 channels |
| Human Attributes | Top color, Top type, Bottom color, Bottom type, Hat, Bag, Age, Gender and umbrella |
| Motor Vehicle Attributes | License plate, Plate color, Vehicle body, Vehicle model, Vehicle logo, Calling, Seatbelt, Vehicle interior, Vehicle registration location |
| Non-motor Vehicle Attributes | Vehicle model, Vehicle color, Number of persons, Helmet |
| ANPR by Camera (Number of Channels) | Human and vehicle detection on all channels, Supporting up to 8 targets per second |
| License Plate Database Capacity | 1. Create up to 20,000 plate numbers 2. Blocklist and allow list |
| Intelligent Alarm | Face detection, Perimeter protection, Face recognition, Video metadata (Human, Motor vehicles, and non-motor vehicles), IMD+, Stereo analysis, Crowd distribution, People counting, ANPR, Vehicle density, Heat map |
| Abnormality Alarm | Camera offline, Storage error, Disk full, IP conflict, MAC conflict, Login lock, Abnormal behaviour of fan, Cyber security exception |
| General Alarm | Motion detection, Privacy masking, Local alarm |
| Alarm Linkage | Record, Snapshot (panoramic), Local alarm output, IPC external alarm output, Access controller, Audio, Buzzer, Log, Preset, Email |
| Disk Group | Support |
| Alarm Input | 4 channel |
| Alarm Output | 2 channel |
| Hard Disk | 2 SATA ports, up to 16TB. The maximum HDD capacity varies with environment temperature |
| Multi-channel Playback | Up to 16 channels |
| Record Mode | General, Motion detection, Intelligent, Alarm, POS |
| Browser | Chrome, IE9 or later, Firefox |
| Playback Mode | Instant playback, General playback, Event playback, Tag playback, Smart playback (face and motion detection) |
| Smart Phone | iPhone, iPad, Android Phone |
| Backup Mode | USB Device/Network |
| Interface Ports | 2 USB Ports (1 Rear USB 3.0 , 1 Front USB 2.0 ), 1 RS232, 1 RS485 |
| Power Supply | 12 VDC, 4Amp |
| Operating Humidity | 10%–93% (RH) |
